GH1000TC-2 is 2 Axis Lathe CNC Controller 1)Threading Cycle: Following Mode/Interpolate Mode<br /> 2) Support Dual analog voltage(0~10V) & C-axis for Spindle servo(M800)<br /> 3) Support Stepper/Increment/Absolute/EtherCAT/Powerlink Servo for Feeding Axes<br />

Similar As Siemens 2Axis Lathe CNC Controller


GH1000TC-2 is 2 Axis Lathe CNC Controller 1)Threading Cycle: Following Mode/Interpolate Mode
2) Support Dual analog voltage(0~10V) & C-axis for Spindle servo(M800)
3) Support Stepper/Increment/Absolute/EtherCAT/Powerlink Servo for Feeding Axes
Send Inquiry

Similar As Siemens 2Axis CNC Controller USB CNC Control System Kit With ATC+PLC CNC Lathe Controller

1000MC-4

Number of control axes

2 axes (X, Z)

Minimum programming

0.001mm

Maximum programming

± 99999.999mm

Top speed

30m / min

Feed speed

0.001-15m / min

Manual continuous

One axis or simultaneous multi-axis

Interpolation method

Straight line, arc, thread interpolation

Tool offset

Length compensation, nose radius C compensation

Spindle functions

Gear, dual analog control, rigid tapping

Handwheel functions

Panel type, plug-in hand-held

Screen saver function

Screen saver function

Communication function

RS232, U disk interface

Compensation function

Knife compensation, between compensation, screw compensation, radius compensation

Program editing

Male / English, relative / absolute programming

Limit function

Software limit, hardware limit

Pre-reading function

Short line preprocessing 10,000 lines

Password protection

Multi-level password protection

Input and output

I / O point 24X24

PLC programming

The user is free to design PLC function

Acceleration and deceleration control

Linear acceleration and deceleration, the number of additions and subtractions

Encoder lines

Any setting

User macro program

Yes

Electronic gear functions

Yes

Number of control axes

2axes (X, Z )

Minimum programming

0.001mm


The 1000TC-2 lathe CNC system is a very popular control CNC product in the 1000TC series.

It adopts high-performance dual-core CPU and ultra-large-scale programmable gate array integrated circuit chip FPGA to form the control core to realize μ-level precision motion control.


Application: CNC Lathe & Turning Machinery and specially automatic equipment

The CNC machine tool controller refers to the program control system of the computer numerical control machine tool. Able to logically process programs with control codes or other symbolic instructions, decode them by the computer, so that the machine tool executes the prescribed actions, and the blanks are processed into semi-finished parts through tool cutting, which greatly improves mold processing Productivity

CNC Controller, including economic type, standard type, high-performance type, and Modbus type( which can support EtherCAT/Powerlink). It can be 16 axes at max.




QQ20210701150818

QQ20210701150800

GH always do good product and service to our clients


FAQ

Q: Are you a trading company or manufacturer?

A: We are professional manufacturer cnc system products. And we trade our products with our clients directly.



Q: Can you do OEM and ODM?

A: Yes, OEM and ODM are both acceptable. The material, color, style can customize, the basic quantity we will advise after we discuss.



Q: Can we use our own logo?

A: Yes, we can print your private logo according to your request.



Q: How many different types of products your company manufactures?

A: Now we have more than 300 products. We have a strong advantage of OEM, just give us the actual products or your idea that you want, we will manufacture for you.



Q: When can I get the price?

A: Usually we quote within 8 hours after we get your inquiry.



Q: What’s your MOQ?

A: If we have the products in stock, it will be no MOQ. If we need to produce, we can discuss the MOQ according to the customer’s exact situation.


Q: How long is your delivery time?

A: The general delivery time is 4-6 days after receiving your order confirmation. , if we have the goods in stock, it will only take 1-2 days.



If you have another question, pls feel free to contact us as below.

Any order pls do not hesitate , we must do good support to you ! come on !
